Waterproof Constant Current LED Driver 65W
SMT-060-1050CW
Non-dimmable LED Driver
SMARTS
SMARTS CW series waterproof constant current led driver current is 1400MA, input voltage is 100-265vac, passed CE certification, mainly sold in Europe, mini body, easy to install, with two-year war...
SMARTS CW series waterproof constant current led driver current is 1400MA, input voltage is 100-265vac, passed CE certification, mainly sold in Europe, mini body, easy to install, with two-year warranty, can protect 65W LED downlight longer time
| MODEL | SMT-090-700CW | SMT-070-0900CW | SMT-060-1050CW | SMT-046-1400CW | |
| OUTPUT | DC VOLTAGE | 45V | 70V | 60V | 46V |
| RATED CURRENT | 700ma | 900mA | 1050mA | 1400mA | |
| VOLTAGE RANGE | 65~90V | 50~70V | 40-60V | 30~46V | |
| RATED POWER | 63W | 60W | 60W | 65W | |
| RIPPLE&NOISE(max) | 500mV | ||||
| VOLTAGE TOLERANCE | ±5% | ||||
| LINE REGULATION | ±5% | ||||
| LOAD REGULATION | ±5% | ||||
| INPUT | VOLTAGE RANGE | 100-265Vac | |||
| FREQUENCY RANGE | 47~63Hz | ||||
| POWER FACTOR(Typ.) | ≥0.91 | ||||
| EFFICIENCY(Typ.) | ≥87% | ||||
| AC CURRENT(Typ.) | about 0.31A/120VAC, about 0.38A/220VAC | ||||
| PROTECTION | SHORT OUT | Protection type:Hiccpe mode,recovers automatically after condition is removed | |||
| OVER CURRENT | Protection type:Hiccpe mode,recovers automatically after condition is removed | ||||
| OVER VOLTAGE | Protection type:Hiccpe mode,recovers automatically after condition is removed | ||||
| ENVIRONMENT | WORKING TEMP. | -30~+50℃ (Refer to output load derating curve) | |||
| WORKING HUMIDITY | 20~99% RH non-condensing | ||||
| STORAGE TEMP.,HUMIDITY | -40~+80℃,10~99%RH,IP67 | ||||
| SAFETY&EMC | SAFETY STANDARDS | EN61347-1;EN61347-2-13;SELV | |||
| WITHSTAND VOLTAGE | I/P-O/P:2KVAC I/P-FG:2KVAC O/P-FG:0.5KVAC | ||||
| EMC Test Standards | EN55015;EN61000-3-2;EN61000-3-3; | ||||
| EN61347;EN61000-4-2,3,4,5,6,8,11; | |||||
| NOTE | 1.All parameters NOT specially mentoned are measured at 120VAC/220VAC input,rated load and 25℃ of ambient temperature. | ||||
| 2.Ripple&noise are measured at 20MHz of bandwidth by using a 12" twisted pair-wire terminated with a 0.1uf&10uf parallel capacitor. | |||||
| 3.Tolerance:includes set up tolerance,line regulation and load regulation. | |||||
