No Certification Waterproof LED Power Supply 150W
SMT-024-150VN
Non-dimmable LED Driver
SMARTS
SMT-012-150VN is a 150W non-dimmable waterproof led driver ip67, input voltage is 100-265vac, constant voltage working mode, full body aluminum shell, can effectively waterproof and dustproof, good...
SMT-012-150VN is a 150W non-dimmable waterproof led driver ip67, input voltage is 100-265vac, constant voltage working mode, full body aluminum shell, can effectively waterproof and dustproof, good waterproof performance, with a two-year warranty Good protection of 150W LED floodlight.
| MODEL | SMT-012-150VN | SMT-024-150VN | |
| OUTPUT | DC VOLTAGE | 12V | 24V |
| RATED CURRENT | 12.5A | 6.25A | |
| CURRENT RANGE | 0~12.5A | 0~6.25A | |
| RATED POWER | 150W | 150W | |
| RIPPLE&NOISE(max) | 150mV | 150mV | |
| VOLTAGE TOLERANCE | ±0.5V | ±0.5V | |
| SETUP RISE TIME | 80ms/220VAC | ||
| HOLD UP TIME(Typ.) | 60ms/220VAC | ||
| INPUT | VOLTAGE RANGE | 170~265VAC | |
| FREQUENCY RANGE | 50~60Hz | ||
| POWER FACTOR(Typ.) | |||
| EFFICIENCY(Typ.) | ﹥83% | ﹥84% | |
| AC CURRENT(Typ.) | 1.22A/220VAC | 1.20A/220VAC | |
| INRUSH CURRENT (Typ.) | COLD START 50A/220VAC | ||
| PROTECTION | Short circuit | Protection type:recovers automatically after condition is removed | |
| Overload | 12.5-15.5A | 6.25-7.75A | |
| Over temperature | Protection type:Shut down o/p voltage,re-power on to removed | ||
| ENVIRONMENT | WORKING TEMP. | -30~+55℃ (Refer to output load derating curve) | |
| WORKING HUMIDITY | 20~99% RH non-condensing(Waterproof) | ||
| STORAGE TEMP.,HUMIDITY | -40~+80℃,10~99%RH | ||
| SAFETY&EMC | SAFETY STANDARDS | EN61347-1;EN61347-2-13;SELV;IP67 approved | |
| WITHSTAND VOLTAGE | I/P-O/P:3.75KVAC I/P-FG:2KVAC O/P-FG:0.5KVAC | ||
| EMC Test Standards | |||
| NOTE | 1.All parameters NOT specially mentoned are measured at 220VAC input,rated load and 25℃ of ambient temperature. | ||
| 2.Ripple&noise are measured at 20MHz of bandwidth by using a 12" twisted pair-wire terminated with a 0.1uf&10uf parallel capacitor. | |||
| 3.Tolerance:includes set up tolerance,line regulation and load regulation. | |||
