0-10V Dim Multi-Current Driver 10W (DIP Adjustment)
SMT-M-010CD
0-10V Dimmable LED Driver
SMARTS
The 0-10V dimmable constant current driver is DIP adjustment, with the feature of Multi-current with dip swith selectable. A wide DC voltage 3-42V. The output current range is from 100mA-450mA.
The 0-10V dimmable constant current driver is DIP adjustment, with the feature of Multi-current with dip swith selectable. A wide DC voltage 3-42V. The output current range is from 100mA-450mA.
※Input terminals "Black" and "White" to connect to AC L and N.
※Output LED SEC output Positive (LED+) , output negative(LED-). Connected to LED light.
※Output terminals DIM (+) to 0/1-10V dimmer signal(+ ),DIM (-) white connect to 0/1-10V dimmer signal (-)
※Please DO NOT connect “DIM-“ to “LED-“, “DIM+” to “ LED+” ,or other incorrect connection.
Note: Please make sure you connect these correctly otherwise your product will not function correctly and could be damaged
